• Technical Data Sheet

Main usage:

It is used to etch copper to get line. there are acidic and alkaline two kinds of etching liquor.

Main Technical Parameters:

1. max PCB developing size: 500*300mm

2. developing way: double size spray

3. speed: 90-120 seconds

4. liquor capacity: 8-10L

5. head: 8

6. heating temperature: 40-50℃

7. power consumption: 2000W

8. power: AC220V

9. dimension: 900*500*420mm
